RoHs Grain Powder Metal Injection Molding Feedstock Carbonyl 50r/Min

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  RoHs Grain Powder Metal Injection Molding Feedstock Carbonyl 50r/Min Get Best Price

Product Details:
Place of Origin: China
Brand Name: KADAM
Certification: RoHs, Reach, MSDS...
Model Number: None
Payment & Shipping Terms:
Minimum Order Quantity: 50KG
Price: Negotiatable
Packaging Details: Plastic Drum
Delivery Time: 5-8 work days.
Payment Terms: T/T
Supply Ability: 300MT per month.
Contact Now
Detailed Product Description
Product Name: MIM Feedstock Brand: KADAM
Certificate: ROHS & REACH Type Of Substrate: Carbonyl
Shape: Grain Size: Standard
Delivery Terms: FOB Shenzhen Port Payment Terms: T/T In Advance
Package: Plastic Bucket MOQ: Could Be Negotiatable
Application: All Available Fabrication Type: POWDER INJECTION MOLDING
High Light:

RoHs Metal Injection Molding Feedstock

,

Grain Metal Injection Molding Feedstock

,

50r/Min Powder Injection Molding

Model: KDM420, KADAM MIM Feedstock Stainless Steel Series.



RoHs Grain Powder Metal Injection Molding Feedstock Carbonyl 50r/Min 0Product Description:The water atomized powder is based on the nitric acid catalytic debinding system and can be used directly for injection molding material granules to produce 420A martensite stainless steel sintering parts.

Product Standard:



Item Unit Specification Test method
Melt flow index (MFI) g/10min 1000±500 ISO1133
Green part density g/cm3 5.35±0.03 ISO3369
Sintering density g/cm3 ≥7.6 ISO3369



Standard Processing:Standard injection molding machine for thermoplastic resins, based on the nitric acid catalytic debinding system.



Injection Molding:



Injection

temperature

 Zone 1 Zone 2 Zone 3 Nozzle
  180℃ 185℃ 190℃ 195℃
Mold temperature 90 ~ 125 ℃
Screw speed 50 r/min
Injection speed 10 cm3/s
Molding pressure 900 bar
Holding pressure 900 bar
Holding time 0.1~3 s









RoHs Grain Powder Metal Injection Molding Feedstock Carbonyl 50r/Min 1



RoHs Grain Powder Metal Injection Molding Feedstock Carbonyl 50r/Min 2





RoHs Grain Powder Metal Injection Molding Feedstock Carbonyl 50r/Min 3



RoHs Grain Powder Metal Injection Molding Feedstock Carbonyl 50r/Min 4
